產品介紹

高速型快速卷門（MEW-KJMC1-104）

High speed fast roll-down metal door（MEW-KJMC1-104）

高速型快速卷門適用于醫藥，食品，電子，潔凈廠房（1000級至10萬級），卷煙，印刷，紡織，購物中心、超市及其它輕工業廠房的區域隔離。

High speed fast roll-down metal door is suitable to the medicine, food, the electron, pure workshop (1,000levels to 100,000 levels), cigarette, printing, spinning and weaving,shopping center, supermarket and other light industry workshops regionisolation.

        性能：

密封性強，不積塵，高穩定性，易清洗，符合GMP要求。速度為0.5-0.8 m/s。

        Performance:
Leak-proof quality strong, does not accumulate the dust, the highstability, is easy to clean, conforms to the GMP requirement. Thespeed is 0.5-0.8 m/s.

        安全性能:

兩套紅外線安全保護系統，兩個桔黃色光電管閃光燈，黃色和黑色的門罩。

在一些風力不大的環境下，可選用滾筒式高速門以達到分割內部空間的目的。

由烤漆鋼板等部件組成的兩個支撐立柱，分別起到邊部導軌和支撐橫梁的作用。PVC密封板的應用，將被分割部分的空間完全隔開，同時增加了整體結構的緊湊性。

滾筒固定于橫梁內，門簾固定于滾筒上，滾筒轉動帶動門簾上卷。

        Security performance:
Two prints portions in red the outwires safekeeping of security system, two orange coloredlights electric tubes flashing light, yellow and black gate cover.

Under some wind power not big environment, may select the roller high speed gate to achieve the division interior space the goal.
Two struts columns which by part and so on baking varnish steel plateis composed, separately plays side a guide rail and the strutcrossbeam role. The PVC dense closing board application, is dividedthe partial spaces completely to separate, simultaneously increasedoverall construction compact.
The drum fixes in the crossbeam, the curtain fixes in the drum, on thedrum rotation impetus curtain curls.

        密封性能：

底端、外包布的橡皮隔氣簾，門體中間鋁制加強筋，底部鋁制夾板及密封底簾，起到卷門配重密封作用。

        Sealing property:
The bottom end、outside the packing sheet rubber separates is mad thecurtain，The gate body middle aluminum system stiffener, the base aluminumsystem clamping plank and the dense back cover curtain, play roll-down metal doorthe counterweight seal role.

        門簾特征:

門簾含有水平鋁合金肋條，可抵御強風沖撞，門簾底部配以鋁合金肋條和橡膠底密。根據客戶要求可開透明視窗。當?shù)孛媲闆r不太好時，為了達到完美的平衡效果，底部也可配一個同樣材質的門簾。邊框和門簾緊密安裝。

        Curtain characteristic:
The curtain includes the horizontal aluminum alloy rib, may resist thegale to dash, the curtain base matches by the aluminum alloy rib and rubber sole dense . May operate the transparent Windows according tothe customer request. When the local surface situation not too isgood, in order to achieve the perfect balanced effect, the base alsomay match a similar material quality the curtain. Frame and curtainclose installment.

        動力性能：

IP55制動電機；0.55千瓦到0.9千瓦，380V三相；1500轉/分；承載大負荷S4型。

        Power performance:
IP55 applies the brake the electrical machinery； 0.55 kilowatt to 0.9kilowatt, 380V three-phase； 1500 revolution of/minute； The loadbearing greatly shoulders S4.

        操縱盒：

IP55盒，可調高反射延時的自動和手動循環系統，保險（絲）控制開關式或三相電源保護。

        Maneuver box:

The IP55 box, may adjust the high reflection time delayto be automatic and the manual circulatory system, the insurance(silk) the controlling switch type or the three-phase power sourceprotection.

        尺寸:

其設計適用于開啟尺寸高度或?qū)挾炔怀^4500mm的情況，特殊應用可由民爾旺公司技術人員研究解決。大尺寸：4500mm×4500mm。

        Size:
Its design is suitable to opens the size highly or the width does notsurpass 4500mm the situation, the special application may you theprosperous company technical personnel study the solution by thepeople. Greatest size: 4500mm×4500mm.

        主體配置選項:

不銹鋼型：全部主體鋼構選用不銹鋼。

普通型：全部主體鋼構選用碳素鋼。

        Main body disposition option:

Stainless die: The complete main body steel construction selectsthe stainless steel.
Ordinary: The complete main body steel construction selects the carbonsteel.
